- Depth behind dash is 2.5″ at shafts
- Dimensions: 222mm W x 64mm Hx 70mm D
- 11.5 – 16.0 volts DC negative ground input – can be operated on 6 volts with power inverter
- Maximum power = 180 watts RMS (45 watts x 4 speakers 4Ω, 14.4V, 1kHz)
- Do not use original speakers
- Uses original antenna
- Sensitivity (FM S/N 30dB) typ 5 dBµ, (AM S/N 20dB) typ 29 dBµ
- Digitally tuned receiver with analog display
- Standard (Motorola) antenna jack ½” D-shafts on controls for mounting (same size and thread as original shafts)
- All controls easily accessible. Volume, Bass, Treble, Balance, Fader and Tuning from original looking controls
- Memory retention (presets, fader and band settings) more than 40 years with power disconnected
- Additional line outs and output options: 3 RCA jacks for left channel, right channel, and sub-woofer
- 3.5 mm phone jack for input from iPod, satellite radio or MP3 player
- Switch selectable for 1,2,3 or 4 speakers
- Switch selectable for North America or Europe mode
- Includes a 6 foot 3.5mm male-to-male auxiliary cable with every radio
- Bluetooth 3.0 EDR compliant
- Built in microphone for HFP (hands-free profile)
- HSP, A2DP, AVRCP profiles supported
- Programmable audio equalizer
- Place/answer calls or stream your favorite programs while maintaining original appearance!
