- Small size, BIG features!
- 83mm case depth allows room for electric wipers, air conditioning
- AM dial scale in foreground looks original – FM dial scale in background
- Analog controls look and feel like the original radio
- All controls easily accessible. Volume, bass, treble, balance, fader and tuning from original-looking controls
- LED dial lights will never need replacing
- Digitally tuned AM/FM/Stereo front end provides stable, high quality reception
- 11.5 – 16.0 Volts DC negative ground input only
- Maximum power = 180 watts RMS (45 watts x 4 speakers 4Ω, 14.4V, 1kHz)
- Do not use original speakers
- Uses original antenna
- Sensitivity (FM S/N 30dB) typ 5 dBµ, (AM S/N 20dB) typ 29 dBµ
- 10 presets (5 AM, 5FM)
- Digitally tuned receiver with analog display
- Dimensions: 229mm W x 83mm H x 117mm D. Depth behind dash is 83mm at shafts
- Auxiliary inputs (RCA jacks). Standard (Motorola) antenna jack
- ½” D shafts on controls for mounting (same size and thread as original shafts)
- Memory retention (presets and other user settings) more than 40 yearswith power disconnected
- Additional line outs and output options: 3 RCA jacks for left channel, right channel, and sub-woofer
- 3.5 mm phone jack for input from iPod, satellite radio or MP3 player
- Switch selectable for 1,2,3 or 4 speakers
- Switch selectable for North America or Europe mode
- Includes a 6 foot 3.5mm male-to-male auxiliary cable with every radio.
- Bluetooth 3.0 EDR compliant
- Built in microphone for HFP (hands-free profile)
- HSP, A2DP, AVRCP profiles supported
- Programmable audio equalizer
- Place/answer calls or stream your favorite programs while maintaining original appearance!
